Spar-VTOL
Spar-V: Professional-Grade Fixed-Wing UAV for Versatile VTOL Applications
The Spar-V is an 8 kg-class fixed-wing UAV engineered for precision, efficiency, and mission adaptability across demanding commercial and industrial applications. Combining advanced aerodynamics with a lightweight composite airframe, it delivers exceptional stability, endurance (optimized via a high lift-to-drag ratio design), and rapid deployment in sectors including aerial surveying, infrastructure inspection, urban planning, and flight training/certification programs.
Key features include:
Modular Payload Integration: Supports multi-spectral cameras, Sony A7R series, 3D photogrammetry systems, and stabilized gimbals, with a standardized interface for seamless sensor interoperability.
Open-Architecture Flight Control: Compatible with commercial-grade autopilots and PIXHAWK open-source systems, enabling tailored mission configurations and software integration.
Operational Efficiency: Tool-free rapid assembly/disassembly (sub-10 minutes) and compact transport design minimize downtime and logistical overhead.
Designed for professionals, the Spar-V prioritizes flight reliability, reduced energy consumption, and scalable data acquisition capabilities—ensuring cost-effective performance for high-intensity operational cycles.
Performance parameters
Material:EPO ( Fibreglass version available upon request)
Wingspan: 2220mm
Body length: 1200mm
Payload: 1.2Kg
Maximum take-off weight: 8Kg
Cruising time: 150min (no load)
Transport box size: 126cm*36cm*36cm
Recommended flight speed: 17M/S-20M/S
Stall speed: 13M/S
Maximum level flight speed: 30M/S
Solid state battery: 6s 32000mah
The whole machine adopts modular design, which can be quickly assembled for flight operation. The handbag is 125cm*35cm*35cm long and can be placed in the back seat of a car for transportation, which is light and portable.
